Бренд

Wisecoco

Состояние товара

Новый

Материал

IPS

Разрешение дисплея

2560x1440

Диагональ экрана

> 3"

Номер модели

for LS060R1SX02

Тип

ЖК-дисплей

Набор LCD

Да

Diagonal Size

6.0 inch

Model

LS060R1SX02

Pixel Format

1440(RGB)*2560 [Quad-HD]

Active Area

74.52(H)*132.48(V) mm

Outline Dim

76.92(H)*140.13(V) *1.35(D) mm

Luminance

450 cd (Typ.)

Contrast Ratio

1300:1 (Typ.) (TM)

Viewing Angle

80/80/80/80 (Typ.)(CR≥10)

Operating Mode

New Mode2, Normally Black, Transmissive

Interface Type

50 pins MIPI (2 ch, 4 data lanes) , Connector

Environment

Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C
