Легкая и удобная в эксплуатации SMT машина для переплавления/12 зон печь для горячего воздуха
265 128 руб.
Характеристики
- Бренд
- HUAQIZHENGBANG
- Применение
- SMT mass production welding
- Номер модели
- ZB1230PF-PC
- Heat zone numbers
- 12 zones
- Heat method
- Hot wind
- Cooling zone numbers
- Two natural air cooling
- Heating zone length
- 2080mm
- Width of net belt
- 300mm
- PCB size
- width Max.280mm
- Height of net belt
- 880±20mm
- Transport speed of net belt
- 0~1500mm/min
- Power supply
- AC380V±10% 50Hz
- Starting power
- 14KW
- Working power
- 5KW
- Heating up time
- 15~20 mins
- Time of passing through the machine
- 3.5~5.5mins
- Range of temperature control
- Indoor temperature---400 degrees
- Method of temperature control
- PID close-cycle caculate method
- Outline size
- L3500*W710*H1250mm
